Hard Rock Bit Drilling Bucket Rock Tools 800mm For Drilling Equipments
Hard Rock Bit Drilling Bucket
,Drilling Bucket with rock drilling teeth
,800mm Rock Tools Drilling Bucket
Premium Hard Rock Bits: High-Quality Rock Drilling Teeth for Sale
Product Description
1. Efficient Material Cleaning: Our hard rock bits are specifically designed for cleaning material from holes that augers cannot retrieve. The operator can easily insert the tool into the hole with the door open, lowering it to the bottom and making a few revolutions before reversing the machine to close the door. With its vented design, the operator can effortlessly pull the tool up to the top of the shaft, lower it to the ground, and open the door by placing the drill in forward motion.
2. Versatile Opening System: Choose between a half-automatic or manual mechanical bottom open system, both equipped with a built-in ventilation pipe. This flexible option allows for optimal control and adaptability to various drilling scenarios.
3. Enhanced Performance: Our hard rock bits feature a cast pilot with rock drilling bits, arc guide plate teeth arrangement, and a double unlocking system. This combination ensures superior performance, reliability, and precision during drilling operations.
4. Ventilation Hole: The hard rock bits are designed with a throughout ventilation hole, allowing for efficient air circulation and cooling during drilling tasks. This feature contributes to extended tool life and optimal performance.
5. Wear Protection: Hard facing strips are incorporated into the design to provide exceptional wear protection, increasing the longevity of the rock drilling teeth. This ensures durability and reduces the need for frequent replacements.
6. Applicable Layers: Our hard rock bits are suitable for various layers, including gravel, pebble, and highly or medium weathered rock. Experience reliable performance and efficiency across a range of drilling conditions.
| Technical Specification of Drilling Buckets with rock drilling Teeth | |||
| drilling Dia. | Shell HIT | Shell Thickness | Weight |
| (mm) | (mm) | (mm) | (kg) |
| 600 | 1200 | 16 | 654 |
| 800 | 1200 | 16 | 926 |
| 900 | 1200 | 16 | 1100 |
| 1000 | 1200 | 16 | 1206 |
| 1200 | 1200 | 16 | 1510 |
| 1500 | 1200 | 16 | 2035 |
| 1800 | 1000 | 20 | 3370 |
| 2000 | 800 | 20 | 3784 |
| 3000 | 800 | 20 | 7200 |
Product Details
FAQ
1: How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment
2: What can you buy from us?
Rotary Drilling Rig,Hydraulic Pile Breaker,Clamshell Telescopic Arm, drilling tools
3: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
